Features of MX3G HMI PLC All-in-one:
1. Super function. The PLC is compatible with FX3S PLC, and the operation speed is fast.
2. Highly integrated. Digital points Max 24 inputs and 24 outputs, digital output optional transistor or mixed output;
analog points Max 9 inputs and 2 outputs. Comes with 2 PLC programming ports (RS232{Type-C port) and 1 HMI
download port(Type-C port).
3. Support several high-speed counting and high习peed pulse. Acceleration and deceleration are independent; the
total of high-speed counting+ high-speed pulse cannot exceed 300KHz.
4. Special encryption. HMI and PLC can be encrypted separately, and the PLC password can be set as 12345678 to
completely prevent reading the progrrm. [Note:P LC only supports 8-bit password encryption]
5. PLC is compatible with software GX Developer8.86Q and GXWorks2, HMI is TPWorks programming software.
6. The thermocouple input can be customized according to customer re q uirrments. More sppcifications can be
customized in bulk orders.

7" 800*480 TFT LCD
High precision and high reliability resistive touch
panel
Natural cooling system
IP65 panel protection level
LED backlight
Built-in storage memory and perpetual calendarProvide a large number of vector galleries andself-built galleries
Software function templated and personalizedcoexistence
Support multi-language, batch translation functionImport and export of batch data and recipes

HARDWAREINTERFACE
OV 24V S/s XO0~X07 X10~XISLN FG CO YOO YOI CI YO2 YO3 C2 YO4 VOS C3Y6 Y7 YIO YIIM3S-24MT/MRT
OV 24V S/S X00~X07 XLO~XL7 X20~X27N FG CO YOO YOL CL YO2 YO3 C2 Y04~Y07C3 YLO~YL3 ·C4 YL4~YL 7 °M3S-40MT/MRT
